► Compact size design and easy installation
► Built-in power amplifier
► High efficiency Class D design
► One Dante input channel
► Dante Network audio transmission
► PoE power supply: IEEE 802.3AT standard
► Inexpensive Cat 5e/6 cabling
► Application: Conference room, Multi-Func-tion Hall, Shopping Mall, School, etc.
Dante Power Amplifier Specification:
Channel number: 1
Audio input type: Dante Network
Connector: RJ-45
Speed: 100M/1000M bps
Network Cable: Cat5e, Cat6
Maximizing power output: 40W(4 ohm)802.3at - D40P 20W(8 ohm)802.3at - AP-D40P 100W(4 ohm)802.3at - AP-D100P 60W(8 ohm)802.3at - AP-D100P
Output connector: 3 Pin Phoenix Connector
Route control: Dante Controller
Frequency response: 20Hz - 20kHz
Total Harmonic Distortion: <0.3%
SNR: >100 dB (A-weighted)
Protection function: Over current, High temperature , Overload / short circuit Cooling mode: Natural convection cooling
Power input mode: PoE+ ,compatible with 802.3af
System power efficiency: >70%
Dimension: 65.4×31×119.5 mm (WxHxD) - AP-D40P;105×44.1×149.6 mm (WxHxD) - AP-D100P
