1. The speaker manager supports multi-channel analog signal input and output for multi-speaker scene signal distribution management;
2. Built-in high-performance DSP processing chip, 24bit, 48kHz processing capability, high-performance A/D and D/A converters;
3. Comes with TFT interactive LCD screen and embedded GUI interface for quick parameter adjustment;
4. 512-order custom FIR filter with stability and linear phase;
5. Input channels include: mute, gain, delay (0-180ms), 31-band graphic equalizer, expander, compressor, sounder, and gain functions;
6. The output channel includes: delay (0-60ms), frequency divider (Butterworth/Bessel/Linkwich filter type 12dB/24dB/36dB/48dB filter slope, FIR filter), 15 segments Parametric equalizer, gain, limiter functions;
7. Professional PC control software, connected through USB or RJ45 cable to realize PC software control settings;
8. The software can add, route and manage multiple online devices;
9. Support input and output channel copy function;
10. Support the mutual binding function of input and output channels;
11. Supports the saving, calling, importing and exporting of multiple sets of scenes;
12. The panel is equipped with a switch for the rotary encoder selection menu, which is easy to operate;
13. Configure bidirectional RS232 interface and standard Ethernet control interface, and open relevant protocol documents.
14.Chnnael:2in 6out,4in8out
